Bi Hydro Intuitive

3D WAX PIECES

Fully controllable from a 10.1″ Industrial PC, it gives the possibility to produce about 480 3D hollow pieces of small and medium size per day with any standard wax thanks to the metal tank divided into two parts: one for wax and one for hydro resin.

warranty-sticker

Bi Hydro Intuitive

3D WAX PIECES

Fully controllable from a 10.1″ Industrial PC, it gives the possibility to produce about 480 3D hollow pieces of small and medium size per day with any standard wax thanks to the metal tank divided into two parts: one for wax and one for hydro resin.

Description

The BI HYDRO INTUITIVE injector is characterized by two independent non-expandable workstations, the consistency of the pieces’ weight over time and by two melting tanks for the simultaneous use of two types of waxes.

Two Android 10.1″ Industrial PC are the control unit and are supported by specially developed apps that allow to save recipes with photos and manage and check production orders. Its interconnect-ability to the outside world makes it compatible for Industry 4.0.

It is equipped in both workstations with a digital pressure sensor for the control of the pressures that always allow to check the graph of the vacuum trend on the mold during injection from the IPC, RFID memory readers, 8-cmc injection syringes with final temperature regulation and self-centering clamps with 120x90mm plates.

Gallery

Technical specifications

  • Moulds
    • Min 50 x 30 x 8 mm
    • Max 120 x 90 x 47 mm
  • Machine
    • 58 kg
    • 90 x 38 x 53 cm
  • Box
    • 90 kg
    • 123 x 50 x 70 cm
Data Sheet

Characteristics and components

Pure italian technology
3 years warranty
4.0 Industry
10.1′ Industrial PC
Customizables models
High production
Vacuum chart
RFID microchips
Recipes with photos
Production APP
Interchangeable clamps
Double working stations
Different size of mould
Big clamps
Hydroresin process
3D Hollow wax pieces
Double tank

Compatible optionalsIntuitive Bi Hydro

  • Syringe 32cmc
  • Plates
    • 120x120 cm
    • 130x120 cm
  • Big Clamps
    • 135x135 cm
    • 140x180 cm
    • 160x180 cm
  • Double Pump
